NTNUS3171PZT5G
Manufacturer:
On Semiconductor
Mfr.Part #:
NTNUS3171PZT5G
Datasheet:
Description:
MOSFETs SOT-1123-3 SMD/SMT P-Channel number of channels:1 -200 mW -20 V Continuous Drain Current (ID):150 mA
| Parameter | Value |
|---|---|
| Length | 850 µm |
| Width | 650 µm |
| Max Operating Temperature | 150 °C |
| Min Operating Temperature | -55 °C |
| Number of Pins | 3 |
| Height | 400 µm |
| Packaging | Reel |
| RoHS | Compliant |
| Number of Elements | 1 |
| Lifecycle Status | Production (Last Updated: 2 months ago) |
| Max Power Dissipation | 125 mW |
| Power Dissipation | -200 mW |
| Number of Channels | 1 |
| Input capacitance | 13 pF |
| Continuous Drain Current (ID) | 150 mA |
| Rds On Max | 3.5 Ω |
| Drain to Source Voltage (Vdss) | 20 V |
| Turn-On Delay Time | 30 ns |
| Turn-Off Delay Time | 196 ns |
| Element Configuration | Single |
| Fall Time | 145 ns |
| Rise Time | 56 ns |
| Drain to Source Resistance | 7 mΩ |
| Gate to Source Voltage (Vgs) | 8 V |
| Drain to Source Breakdown Voltage (Vds) | -20 V |
| Schedule B | 8541210080 |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 2 months ago) |
| Gate to Source Threshold Voltage | 1 V |
| FET Type(Transistor Polarity) | P-Channel |
